Precision Balances
- Ohaus - Explorer Plus™ High Capacity EXP
Get our best quote for one or multiple products.
Why buy from Geneq? - find out more
Do you have a question?
Model : EXP24001
- Maximum Capacity ： 24,000 g
- Readability ： 0.1 g
- Pan Size ： 12.2 in x 14.8 in (311 mm x 377 mm)
Model : EXP24001N
- Maximum Capacity ： 24,000 g
- Readability ： 0.1 g
- Pan Size ： 12.2 in x 14.8 in (311 mm x 377 mm)
Model : EXP35001
- Maximum Capacity ： 35,000 g
- Readability ： 0.1 g
- Pan Size ： 12.2 in x 14.8 in (311 mm x 377 mm)
Model : EXP35001N
- Maximum Capacity ： 35,000 g
- Readability ： 0.1 g
- Pan Size ： 12.2 in x 14.8 in (311 mm x 377 mm)
Model : EXP65001
- Maximum Capacity ： 65,000 g
- Readability ： 0.1 g
- Pan Size ： 12.2 in x 14.8 in (311 mm x 377 mm)
Model : EXP65001N
- Maximum Capacity ： 65,000 g
- Readability ： 0.1 g
- Pan Size ： 12.2 in x 14.8 in (311 mm x 377 mm)
Engineered for Accuracy, Designed for Demanding Applications
The new Explorer EXP series offers a premium weighing performance, compliance support and data traceability. The advanced features take the EXP to the next level by optimizing the user experience. This Flagship balance is crafted to meet the most demanding requirements of modern scientific research.
Features
Seamless setup with digital level bubble, touchless sensors, 7-inch glass touchscreen and terminal status light. A large SST pan and weigh below hook makes it easy to weigh large loads up to 65Kg.
Ensure compliance with 4-level user system, password protection, and 100k internal system log. The time synchronization NTP function confirms data traceability to meet pharmaceutical regulations.
Advanced communication capabilities with straightforward integration to Laboratory Information Management Systems (LIMS),and hassle-free data transfer with driverless HID for easy data input.
Product Details
Applications
Basic Weighing, Parts Counting, Check Counting, Percent Weighing, Check Weighing, Dynamic Weighing, Totalization, Formulation, Differential, Density Determination, Peak Hold, SQC, Fill Weight Variation, Flow Rate Control
Operation
AC Input: 100-240 VAC 0.5A 50-60 Hz
Communication
USB Host (Type A) x 2, USB Device (Type C) x 1, Ethernet (RJ45) x 1, RS232 x 1; Optional Wi-Fi, Bluetooth Dongle
Display
7-inch TFT 16.7M Color Touch Screen with Glass Overlay
Construction
Modular design, IP54 rated base, Metal base and housing, SST 304 weighing pan, Integral weigh below hook, 3 ambient sensors, 2 touchless sensors, Terminal status light
Design Features
Time Synchronization NTP, Support for HID (Human Interface Device) connection to a computer without the need for drivers, 4 level user management and an internal system log capacity of 100,000 entries, 3000 application sample libraries
| Model | EXP24001 | EXP35001 | EXP65001 |
| EXP24001N | EXP35001N | EXP65001N | |
| Capacity | 24000 g | 35000 g | 65000 g |
| Readability | 0.1 g | 0.1 g | 0.1 g |
| Repeatability (sd.),≤5% of Full Load Typica | 0.08 g | 0.08 g | 0.08 g |
| Repeatability (sd.),5% of Full Load to Full Range | 0.1 g | 0.1 g | 0.1 g |
| Readability d (g) (EXP….N…model) | 0.1 g or 1 g | ||
| Linearity Deviation Typical | 0.07 g | 0.07 g | 0.07 g |
| Linearity Deviation | 0.2 g | 0.2 g | 0.2 g |
| Verification Interval, e (EXP…N.. models only) | 1 g | 1 g | 1 g |
| Approval Class (EXP…N.. models only) | Class II | Class II | Class II |
| Span Calibration Points (g) | 10000g, 15000g, 20000g, 24000g | 10000g, 20000g, 30000g, 35000g | 20000g, 40000g, 60000g, 65000g |
| Weighing Units | g, ct, N, oz, ozt, Grain, dwt, mo, msg, tl H, tl S, tl T, tcl, tola, baht, lb, kg, Custom 1, Custom 2 | ||
| Weighing Units (EXP…N.. model only) | g, ct, oz, ozt, Grain, dwt, lb, kg | ||
| Applications | Basic Weighing, Parts Counting, Check Counting, Percent Weighing, Check Weighing, Dynamic Weighing, Totalization, Formulation, Differential, Density Determination, Peak Hold, SQC, Fill Weight Variation, Flow Rate Contro | ||
| Stabilization Time (typical) | ≤ 1 second | ||
| Sensitivity Temperature Drift (ppm/℃) | 5 | ||
| Min-Weight (typical) * (K=2, U=1%) | 16 g | ||
| Min-Weight (typical) **(USP, K=2, U=0.10%) | 160 g | ||
| Terminal Display | 7-inch TFT 16.7M Color Touch Screen with Glass Overlay, Detachable Terminal | ||
| Display Resolution | 800 x 480 Pixels | ||
| Communication | USB Host (Type A) x 2, USB Device (Type B) x 1, USB Device (Type C) x 1 Ethernet (RJ45) x 1, RS232 x 1; Optional Wi-Fi, Bluetooth Dongle | ||
| Leveling System | 4 leveling feet with Digital Leveling Bubble | ||
| Power Supply | AC Input: 100-240 VAC 0.5A 50-60 Hz | ||
| Weighing Pan Size | Trapezoid Pan 377mm x 311mm | ||
| Environmental Sensor (Load Cell) | Temperature Sensor, Relative Humidity Sensor (RH),Air Pressure Sensor | ||
| Touchless Sensor | 2 Touchless Sensors on the terminal | ||
| Terminal Status Lights | Standard, 7-color Selectable | ||
| Terminal Housing Dimensions (W x D x H) | 205mm x 126mm x 66mm | ||
| Base Housing Dimensions (W x D x H) | 378mm x 311mm x 125mm | ||
| Assembled Dimensions (W x D x H) | 378mm x 438mm x 125mm | ||
| Shipping Dimensions (W x D x H) | 525mm x 665mm x 330mm | ||
| Rechargeable Battery | Li-ion, ICR18650, 14.4V, 2600 mAh (optional) | ||
| Battery Life | Up to 8 hours with brightness ≤50% Up to 5 hours with brightness ≤90% Full charging time: 6 hours | ||
| IP Rating | IP54 (Base only) | ||
| Net Weight | 11.0 kg | ||
| Shipping Weight | 13.8 kg | ||
*The minimum weight (typical) U=1% represents the minimum weight required to meet 1% uncertainty under ideal metrological conditions. Uncertainty of U=1% is not valid to meet USP Chapter 41 requirements, but may be acceptable for other applications.
**USP Chapter 41 is a mandatory United States Pharmacopeia standard. Min-Weight (typical) U=0.10% as listed in the data sheet is to be used as a comparative reference only. The actual minimum weight must be calculated using an on-site repeatability test under actual use conditions. Refer to USP Chapter 41 for more information.
